CL series omni wheel 90°
Series Introduction
CL series omni wheel is 90-degree economy light load omni wheel . there are 2 nylon sliding bearings in every driven wheel . it is aimed to supply the products with high precise ,high economy and high endurance to customers. CL series omni wheel adopts rubber roller and galvanized steel hub , meanwhile it has various mounting dimensions to satisfy different applications.
Parameter Comparison
- Product
- Diameter(mm)
- Wide(mm)
- Wheels
- Bearing
- Bearing Type
- Wheel Material
- Hub Material
- Hub Surface Treatment
- Mount
- Typical Middle Hole Size(mm)
- Weight(g)
- Load(kg)
-
CL-10
- 101.6（4"）mm
- 39mm
- 16
- 32
- Nylon Sliding Bearing
- Rubber
- Steel
- Electro-galvanized
- Flat key/Hexagon Hole/Set Screws/Bearing supports
- 5/6/7/8/9/10/12mm
- 430g
- 50Kg
-
CL-13
- 127（5"）mm
- 39mm
- 20
- 40
- Nylon Sliding Bearing
- Rubber
- Steel
- Electro-galvanized
- Flat key/Hexagon Hole/Set Screws/Bearing supports
- 5/6/7/8/9/10/12mm
- 730g
- 50Kg
| Product |
CL-10
|
CL-13
|
|---|---|---|
| Diameter(mm) | 101.6（4"）mm | 127（5"）mm |
| Wide(mm) | 39mm | 39mm |
| Wheels | 16 | 20 |
| Bearing | 32 | 40 |
| Bearing Type | Nylon Sliding Bearing | Nylon Sliding Bearing |
| Wheel Material | Rubber | Rubber |
| Hub Material | Steel | Steel |
| Hub Surface Treatment | Electro-galvanized | Electro-galvanized |
| Mount | Flat key/Hexagon Hole/Set Screws/Bearing supports | Flat key/Hexagon Hole/Set Screws/Bearing supports |
| Typical Middle Hole Size(mm) | 5/6/7/8/9/10/12mm | 5/6/7/8/9/10/12mm |
| Weight(g) | 430g | 730g |
| Load(kg) | 50Kg | 50Kg |
Product Briefing
High economy
CL series omni wheel have better quality and economical benefit, it can adapt wild application because of its cost-effectiveness.
Steel hub
Self weight is a little heavy , but it has better intensity and resilience.
Reliable, long lifetime, stable quality
